LEOFOTO LS-223C Ranger Carbon Fiber Tripod with LH-25 Ball Head
- 6 kg Maximum Load Capacity
- 38 cm Maximum Height
- 27 cm Folded Length
- Intuitive Ball Head Controls
- 22/19/16 mm Leg Diameter
- Arca-Swiss Compatible Camera Plate
- 3 Section Legs with Secure Twist Locks
- Independent Leg Angles
- Strong, Lightweight Carbon Fiber
Description
Leofoto’s Ranger Series has something for everyone. Their lightweight LS-223C Carbon Fiber tripod is paired with a reliable LH-25 ball head, turning this combo into the ultimate backpack-friendly travel buddy. It’s small and lightweight, making it easy to take anywhere. The 3 leg sections and independent leg angles give you the flexibility needed to frame up a shot just about anywhere.
6 kg Maximum Load Capacity
Compact tripods don’t mean you have to compromise on capacity. The Leofoto LS-223C tripod and LH-25 ball head prove this, combining for an impressive 6kg maximum load capacity. This means it can easily support a huge range of cameras and gear, including DSLRs, mirrorless, and video cameras.
Intuitive Ball Head Control
The LH-25 low profile ball head is designed to be compact, so it complements travel-sized tripods. It has a secure screw-clamp that keeps the Arca-Swiss style quick release plate firmly in place. Intuitive controls for ball lock and panning make it easy for you to change your framing on the fly.
Versatile Height Range
This little Ranger Series tripod is seriously compact, ideal for minimalist travellers and setting up in tight spaces. Individual leg angles offer great flexibility and the twist locks mean quick set-up. A maximum height of 35cm gives you just enough lift when needed, while the 12cm minimum height lets you capture those dramatic ultra-low shots.
Lightweight Carbon Fiber Design
Made with Carbon Fiber leg tubes, the LS 223C is both strong and lightweight, so it’s very easy to slip into your camera bag and take with you almost anywhere. Carbon Fiber perfectly complements the already compact nature of this tripod, making it a no-brainer accessory to bring with you.
Removable Rubber Feet and Spikes
A nice little addition to the Leofoto Carbon Fiber LS-223C tripod kit is its removable rubber feet. They offer a good, solid grip on most surfaces, but can be taken off easily and exchanged for the included spiked feet when you’re working on loose or unstable terrain. Toss the whole thing into its convenient carry case, and you’re good to go, no matter what.
Specifications
Load Capacity |
6 kg |
Weight |
0.72 kg |
Maximum Height with Center Column |
38 cm |
Minimum Height |
10.5 cm |
Folded Lenght |
27 cm |
Leg Sections |
3 |
Leg Diameter |
22/19/16 mm |
Locking System |
Twistlock |
Minimum Operating Temperature |
-40 Grad |
Material |
Carbon Fiber |
Leg Angle |
85°/55°/25° |
Spikes |
3/8 Zoll |
LEOFOTO LH-25 Mini Ball Head
- Low Centre of Gravity: Height 67mm
- Made of Aircraft Aluminum Alloy
- 90° Portrait Notch
- Load Capacity: 6kg
- Non-slipping, Grease-free Bearing Balls
- Panning Base with Index Mark for Separate Rotation
- Arca compatibel
- 10-Years Manufacturer Warranty
Description
Made of aluminum with an anodized finish for durability, this LH-25 Mini Ball Head from Leofoto uses a screw-knob clamp at its top to attach to any mounting plate that is 25mm in length. It is made to support gear as heavy as 11 lb for 360° panning, and has a cutout notch at its base to enable 90° tilting in one direction.
The ball head boasts a compact design, with a fixed height of 2.6" and a weight of 6 oz, that makes it easy to travel with and use. A single lever is available for adjusting head position, which pulls out to enable control and fits back in to lock everything in place. The LH-25 has a 3/8"-16 bottom mount and comes with a 3/8" to 1/4" bushing reducer, allowing you to mount it to tripods with either thread size.
Specifications
Load Capacity |
6 kg |
Weight |
178 g |
Tripod Mounting |
3/8"-16 mount, with a bushing adapter available for those with 1/4" screws |
Bubble Level |
no |
Rotation |
360 Degrees |
Tilting |
90 Degrees |
Arca Swiss compatible |
yes |
Ball Diameter |
25 mm |
Height |
67mm |
Indexing Skale |
with |
QR-Plate included |
yes |
Material |
Aircraft Aluminum Alloy |
In the Box
- 1 x LEOFOTO LS-223C Ranger Carbon Fiber Tripod with LH-25 Ball Head
- 1 x Tripod Bag
- 1 x Allen Key
Tripod Components

Cameras and tripods have a long-standing partnership, maintaining relevance and unmatched functionality in a world dominated by image stabilization and Photoshop tricks. Although the form and function of a tripod are much simpler to understand than today’s DSLRs, with their extensive features, selecting the right setup from a variety of manufacturers and seemingly comparable models can be a daunting task. This article outlines the basic types of tripod kits every photographer should consider, and discusses the various categories of tripod heads and legs for those looking to build a custom setup.
Tabletop Tripods

For some, the simplest and smallest solution is often the best, and for this audience, a tabletop tripod offers a particularly compact solution for the everyday photographer. These tripods come in a range of types and sizes and are usually sold as kits with a pre-mounted head and legs. They are typically inseparable and reach a maximum height of no more than 30cm. These tripods are ideal for travelers, hikers, or those photographing in areas where carrying full-sized camera equipment might be restricted. Those needing a table support may also consider a flexible variant, such as the Joby Gorillapod line. These compact and lightweight supports can be used on a traditional flat surface or wrapped around various objects (such as branches, pipes, and handlebars) to stabilize your camera on uneven terrain or create a unique new photographic perspective.
The Tripod System
For the passionate, ambitious, and professional photographer, investing in a modular tripod system—or, for the layperson, a tripod with a removable head and a set of durable, versatile legs—is the preferred choice. Whether purchased together as part of an extended set or separately, investing in a system ensures the user obtains customizable, high-quality equipment that can be adapted to specific photography needs either now or in the future. Below, we outline some of the different options for purchasing a pre-made tripod kit or assembling your own tripod kit using components selected to meet your individual requirements.
The 3-Way Pan-Tilt Head

When most people think about tripod functionality, they envision the movement and brand-licensed style of the classic three-way head. This design remains popular with beginners for its ease of use and relatively precise movement. The head consists of three separate arms controlling vertical tilt, horizontal tilt, and 360-degree panning. To adjust the position of each angle, simply turn the handle for the desired angle, position the camera, and then tighten the handle again to lock the camera in place—it's that simple. Three-way heads are commonly used for landscape, portrait, still-life, macro, or product photography, but they can be used for almost any photographic application.
The Ball Head

The ball head is currently the most modern and generally preferred head style, partly due to its compact size (compared to three-way heads), lightweight build, and ease of adjustment. Unlike the three-way head, ball heads save size and weight by allowing you to use the camera itself as the "handle," positioning the camera in any direction with just one rather than three knobs. Ball heads typically feature dual or triple control, allowing photographers to control the ball’s movement and friction with separate knobs. Tri-control designs often implement a third knob that controls the 360-degree panning separately from the main ball lock. Due to its size and speed, this head style is popular among sports, action, nature, travel, and studio photographers. Like the three-way head, it can also be used for almost any photographic application.
The Gimbal Head

Gimbal heads are practically essential in the world of advanced sports and wildlife photography, as they support the large telephoto lenses that are an undeniable hallmark of the craft. The gimbal head is designed to support and balance large lenses and camera bodies, allowing the user to follow a moving subject vertically and horizontally, and, if properly balanced, retain its last position even when the photographer’s hand leaves the camera. They are generally the largest and heaviest head style, but for photographers who need them, their utility is unrivaled. It is also worth noting that most gimbal heads are not sold with a mounting plate; one must be selected specifically for the lens in use. When investing in a gimbal system, you should always purchase a suitable lens mounting plate that provides enough length to adequately balance your equipment.
The Fluid Head
Since almost every camera now includes advanced video functions, many photographers have begun incorporating video components into their tripod kits, with the fluid head being the most significant of these additions. The fluid head is designed to reduce resistance when recording video, allowing for smooth pans and tilts along two axes, and the integrated "fluid" cartridge reduces unwanted shakes, vibrations, and jitters. While each tripod head has a maximum load capacity, the stated maximum of a fluid head should be seen as a guideline that should never be exceeded. Balanced weight is essential for good fluid head performance, and resistance to an unbalanced load can impair the video-smoothing properties of the head, especially in the hands of beginner videographers.
Material Choice
Tripod legs—whether for beginners or professionals—are a relatively straightforward matter, limited to three simple factors: weight, load capacity, and price. The often heavier, cheaper, and somewhat more durable material for tripod legs is an oldie but goodie: aluminum. Although its weight may not be ideal for travel, aluminum tripods benefit from this weight with increased stability and the ability to withstand daily use and minor impacts. However, aluminum legs are subject to the environment in which they are used, which simply means they heat up in the sun, cool down in the cold, and can rust if not properly cleaned after exposure to freshwater
and saltwater. The second, newer, and more expensive material option is carbon fiber, which has become a darling in the world of outdoor and landscape photography due to its lighter weight and excellent rigidity. Although the price difference between aluminum and carbon fiber has decreased significantly in recent years, it is still substantial for higher-quality tripod brands.
